L-8B/L-8BWP
Features
◎ Suitable for touring performance,live performances,theater,performing, arts halls,dance halls, auditoriums,multi-function rooms ,banquet halls,stadiums(combine with full-range line array speakers to be used).
◎ Used together with L-8/L8WP full -range line array speakers to be hanged to line array system,It’s cabinet width is consistent with the full -range speaker.It is compact,light,weight, very convenient to install the patch,and can provide broader frequency response for the whole line array system. L-8B is optional for L-Series line array speaker.It is suitable particularly for the supplement use of outdoor touring performance low’s frequency.
Specifications
|
System: |
1×18”SUB BASS |
|
System type: |
1×18”passive line array bass |
|
Frequency range: |
35Hz-300Hz(±3dB) |
|
Coverage（H×V): |
Based on the configuration of the linear array× 90° |
|
Power: |
600W(RMS) |
|
Sensitivity (1Watts@1m): |
100dB |
|
SPL: |
Continuous:128dB, Peak :134dB |
|
Nominal impedance: |
8Ω |
|
LF Transducer: |
1×18''woofer/4”voice coil |
|
Enclosure material : |
18mm birch plywood |
|
Finish: |
Black dot paint/waterproof polyurea paint |
|
Grill: |
Black steel with anti-corrosion coating |
|
Dimensions(W×H×D): |
760×600×640mm |
|
NW: |
60kg |
-
