TOP-0408

数字音频处理器

型号：TOP-0408

功能特点：

1、4路输入8路输出，可灵活组合多种分频模式，高、低通分频点均可达20Hz～20KHz；
2、输入：4路平衡式线路输入，采用标准卡侬接口，平衡接法。

3、输出：8路平衡式线路输出，采用标准卡侬接口，平衡接法。

4、DSP芯片处理，48kHz采样率。

5、可存储32个系统预设。

6、输出通道的软压缩阀值，比率，启动时间，恢复时间连续可调。
7、任意通道之间参数设置可以自由复制，以及任意通道可以进行连动调节。

8、内置测试信号发生器，输出方式可选粉红噪声，白噪声及20Hz-20kHz正弦波可调，信号幅度可调。
9、前面板带有输入输出电平指示灯

10、输入、输出有16段参量均衡器，增益控制、噪声门功能、RMS压限、内置的粉红/白噪声发生器，以及可调的延时。分频器的斜率从-6dB/Oct到-48dB/Oct范围内可选。

11、可选配开通全通滤波器功能

主要技术参数：

1、输入阻抗：平衡20KΩ，非平衡10KΩ                                                                                                                                                                                          2、输出阻抗：平衡100Ω，非平衡50Ω                                                                                                                                                                                             3、输入共模拟制比：≥78dB(1KHz)                                                                                                                                                                                     4、输出动态范围：112dBu                                                                                                                                                                                           5、频率相应：20Hz-20KHz(±0.5dB)                                                                                                                                                                                        6、信噪比：>90dB@1KHz 0dBu                                                                                                                                                                                                                                                                                                                                                                                     7、失真度：﹤0.002% OUTPUT=0dBu/1KHz                                                                                                                                                                             8、信道分离度：>100dB（1KHz）                                                                                                                                                                                 9、功耗：≤45W                                                                                                                                                                                                       10、电源:AC110V/220V  50/60Hz                                                                                                                                                                                            11、产品尺寸（宽×深×高）:482mm×260mm×44mm                                                                                                                                                                        12、净重：2.2KG
